Forged / hot rolled Magnesium Alloy Plate sheet Easier Handling For 3C Electrical Computer Applications

Forged / hot rolled Magnesium Alloy Plate sheet Easier Handling For 3C Electrical Computer Applications
Forged / hot rolled Magnesium Alloy Plate sheet Easier Handling For 3C Electrical Computer Applications Forged / hot rolled Magnesium Alloy Plate sheet Easier Handling For 3C Electrical Computer Applications Forged / hot rolled Magnesium Alloy Plate sheet Easier Handling For 3C Electrical Computer Applications Forged / hot rolled Magnesium Alloy Plate sheet Easier Handling For 3C Electrical Computer Applications Forged / hot rolled Magnesium Alloy Plate sheet Easier Handling For 3C Electrical Computer Applications Forged / hot rolled Magnesium Alloy Plate sheet Easier Handling For 3C Electrical Computer Applications

Large Image :  Forged / hot rolled Magnesium Alloy Plate sheet Easier Handling For 3C Electrical Computer Applications

Product Details:
Place of Origin: CHINA
Brand Name: YUECHEN METAL
Certification: ISO9001, SGS, BV
Model Number: AZ31, AZ61, AZ80, AZ91, AM60, ZK60, ME20
Payment & Shipping Terms:
Minimum Order Quantity: 1KG
Price: Negotiation
Packaging Details: Plywood case
Delivery Time: 5days
Detailed Product Description
DAMPING: Absorbs Vibration For Longer Life, While Retaining Dimensional Stability. TOOLING: 4 To 5 Times Greater Tool Life.
FINISH: Up To 5 Times More Machinable Than Rolled Aluminum. CORROSION RESISTANT: A Wide Variety Of Chemical Treatments Exists For Corrosion Protection, Alteration Of Surface Appearance, And To Provide A Base For Painting. Basic Engineering Precautions Averts Galvanic Corrosion.
STRENGTH: Excellent Strength And Stiffness Per Unit Weight. FLATNESS: Eliminates Surface Machining.
NONMAGNETIC: Good For Electrical And Computer Applications. Thermal Conductivity:: 76.9Wm-1k-1
Electrical Resistivity:: 92nΩm Melting Range:: 566 - 632°C
Density: 1.81
High Light:

magnesium based alloy

,

az31b magnesium alloy

Forged / hot rolled Magnesium Alloy Plate sheet Easier Handling For 3C Electrical Computer Applications



ZK60A

ZK60A is a wrought magnesium base alloy containing zinc and zirconium. Increased strength is obtained by artificial aging from the as-fabricated form. ZK60A-T5 has the best combination of strength and ductility at room-temperature of the wrought magnesium alloys.



APPLICATIONS

Forgings and extrusions in ZK60A find application in high strength parts for use primarily where the service temperature is below 150°C. ZK60A forgings can be used where pressure tightness or machinability are required. That parts are dimensionally stable during and after machining is also an important design consideration.

Forgings and extrusions in ZK60A find application in high strength parts for satellites, helicopter gearboxes and rotor hubs, bicycle frames, roadwheels, missle frames and interstage fairings, brake housings and landing gear struts.



SPECIFICATIONS

ASTM B91

ASTM B107/B107M-13



CHEMICAL COMPOSITION

Zinc 4.8-6.2%

Zirconium 0.45% min

Magnesium Balance

Forged / hot rolled Magnesium Alloy Plate sheet Easier Handling For 3C Electrical Computer Applications 0

Dimension Scope

Forgings: Max. length 1000mm, max. width 500mm, max thickness 330mm.

Extrusions: Diameter 6mm - 180mm for round bar; thickness and width 10-220mm for square/rectangular section. Length: 100mm - 6000mm

Thickness and width are inter-dependant.



HEAT TREATMENT

As-fabricated (F) forgings can be converted to the precipitation treated temper (T5) by heating to 150°C for 24 hours, followed by air cooling.



PHYSICAL PROPERTIES

Specific Gravity 1.83

Coefficient of Thermal Expansion 27.1x10 -6 K -1

Thermal Conductivity 121 Wm -1 K -1

Specific Heat 1100 Jkg -1 K -1

Electrical Resistivity 57 nΩm

Modulus of Elasticity 45GPa

Poissons Ratio 0.35

Melting Range 520-635°C



TYPICAL HARDNESS

ZK60A-T6 85 Rockwell E

ZK60A-T5 77 Rockwell E



WELDABILITY

ZK60A is not considered to be weldable by conventional techniques due to hot-shortness cracking. However, resistance welding response is excellent. Friction stir welding can be used to join ZK60A to itself and other magnesium alloys.



MACHINING

ZK60A, like all magnesium alloy forgings, machines faster than any other metal. Providing the geometry of the part allows, the limiting factor is the power and speed of the machine rather than the quality of the tool material. The power required per cubic centimeter of metal removed varies from 9 to 14 watts per minute depending on the operation.



SURFACE TREATMENT

All the normal chromating, anodizing, plating, and finishing treatments are readily applicable.

Forged / hot rolled Magnesium Alloy Plate sheet Easier Handling For 3C Electrical Computer Applications 1

XIAN YUECHEN METAL PRODUCTS CO., LTD. (XYMCO) is one of the leading manufacturer of magnesium alloy products located in Xincheng Hi-Tech Industry Estate, Xi’an, Shaanxi, China, who is specialized in the development, manufacture and supply of magnesium alloy products worldwide included magnesium tooling plate, magnesium alloy plate, magnesium alloy sheet, magnesium alloy slab, magnesium alloy bar, magnesium alloy billet, magnesium alloy rod, magnesium alloy tube, magnesium alloy pipe, magnesium alloy profile, magnesium welding wire, magnesium alloy extrusion, magnesium alloy stamping, magnesium alloy casting, magnesium alloy forging and semi - fabricated component according to customer’s design.



We comply with the specifications:

GB5153-03, GB5154-04, AMS4377G, ASTM B90/B90M-15, MIL-DTL 32333, MIL-T-38749, QQ-M-44B, ASTM B107/B107M-13 and ASTM B91-97

Material grades: AZ31B, AZ61A, AZ80A, AZ91D, AZ41M, ZK60, AM50, AM60, ZM21, MIA, ME20M, EQ21, WE43, WE54, ZE41, etc.



Our main products and capabilities are as follows:

1. Magnesium tooling plate: Max. Thickness: 300mm; Max. Width: 2000mm; Max. Length: 6000mm

2. Magnesium alloy cast slab: Max. Size: 400 x 1000 x 3000mm

3. Magnesium alloy sheet: Min. Thickness: 0.5mm; Max. Width: 600mm; Max. Length: 2000mm

4. Magnesium cast billet: Min. Diameter 90mm; Max. Diameter: 600mm; Max. Length: 6000mm

5. Magnesium alloy extruded wire: Dia.1.0mm – 8.0mm in spool.

6. Magnesium alloy extruded rod: Min. Dia. 8mm; Max. Diameter: 450mm; Max. Length: 3000mm

7. Magnesium extrusions:

Round tube: Max. OD600mmx thickness 125mm

Square tube: 430 x 430mm

Flat bar: 920 x 160mm

U-Shape: 800 x 300mm

Rectangular: 700 x 200mm

8. Magnesium-Lithium Alloy rod, sheet, plate and tube.

XIAN YUECHEN METAL PRODUCTS CO., LTD. (XYMCO) is able to mass produce LZ91, LA91, LA141, MA18 and MA21 magnesium lithium alloys in the form of rectangular or round shape ingot by vacuum melting techniques, and mass produce MgLi wrought alloys and its products of magnesium lithium alloy slab, magnesium lithium alloy bock, magnesium lithium alloy plate, magnesium lithium alloy sheet, magnesium lithium alloy foil, magnesium lithium alloy strip, magnesium lithium alloy coil, magnesium lithium alloy billet, magnesium lithium alloy rod, magnesium lithium alloy bar, magnesium lithium alloy tube, magnesium lithium alloy pipe, magnesium lithium alloy wire, magnesium lithium alloy profile by casting, forging, extrusion and hot rolling process. XYMCO also produces the customized sizes (non standard sizes) magnesium lithium alloy materials and its products according to customers’ requirements.

NPFC - MIL-M-46130 Magnesium-Lihium Alloy Plate, sheet and forgings (LA141A, LS141A and LZ145A)



Our products already were exported to USA, Japan, Israel, India, Germany, Iran, Columbia, Italy and UK. Good quality, good price and good delivery.



Looking forward to your enquiry and hope a prosperous cooperation can be established between us.

Forged / hot rolled Magnesium Alloy Plate sheet Easier Handling For 3C Electrical Computer Applications 2

XIAN YUECHEN METAL PRODUCTS CO., LTD. (XYMCO) R&D the magnesium based Rare Earth Alloys from 2004. They are widely used for aviation, aerospace, machinery, power plant, auto and railway. Following is the available alloys:

Name Alloy Grade Main alloy content (%) Specification Inclusion (%) Form
Mg-Nd Alloy Mg-Nd25 Nd: 25±2% HB7264-96 As per HB7264-96 Square
Mg-Nd30 Nd: 30±2% HB7264-96
Mg-Zr Alloy Mg-Zr25 Zr: 25±2% HB6773-93 As per HB 6773-93 Square, round bar
Mg-Zr30 Zr: 30±2% HB6773-93
Mg-Zr40 Zr: 40±2% HB6773-93
Mg-Sc Alloy Mg-Sc Sc: 2%~10%   As per customer requirement Square, round bar
Mg-Y Alloy Mg-Y Y: 20%~70% High purity Less than 100ppm Round bar
Mg-Gd Alloy Mg-Gd Gd: 20%~70% High purity Less than 100ppm Round bar

Both the small quantity and big quantity per order is available



Other Magnesium based Alloys:



AE811S, ZE41A, WE43, WE54, WE94

Mg-La Alloy; Mg-Sb Alloy; Mg-Ce Alloy; Mg-Sr Alloy; Mg-Er Alloy; Mg-Sn Alloy; Mg-Yb Alloy; Mg-Ir Alloy; Mg-Dy Alloy; Mg-In Alloy; Mg-Re; Mg-Ti; Mg-Re (La); Mg-Co; Mg-Mn; Mg-Si; Mg-Ca; Mg-V; Mg-Fe; Mg-Zn; Mg-Ni; Mg-Al-Sc; Mg-Cu; Mg-Y-Ni; Mg-Al; Mg-Al-Zn.



We also produce special magnesium based master alloys as customer’s requirements.





Our Services:
1. Small order quantity available
2. Professional engineering team and sales team
3. Payment: T/T & Western Union
4. OEM/ODM Supporttable
5. Free samples provided
6. Competitive price and high quality



FAQ:
1. Q: Are you a factory or trading company?
A: We are direct manufacturer located in Xi'an, Shaanxi province, and have our equipment!

2. Q: Are your products customized?
A: Yes,the products in the website are only the common type or the previous types, we can supply the new products according to your requirements or drawings.

3. I do not know how to use your product ?
Do not worry ! We can supply technical guidance together with products.

4. Q: How can I get some samples?
A: Several samples are freely offered for buidling the business long-term relationships and letting our customers believing the quality of our products.
