Rolled AZ31B H26 AZ91D Magnesium Alloy Plate

Rolled AZ31B H26 AZ91D Magnesium Alloy Plate
Rolled AZ31B H26 AZ91D Magnesium Alloy Plate Rolled AZ31B H26 AZ91D Magnesium Alloy Plate Rolled AZ31B H26 AZ91D Magnesium Alloy Plate Rolled AZ31B H26 AZ91D Magnesium Alloy Plate

Large Image :  Rolled AZ31B H26 AZ91D Magnesium Alloy Plate

Product Details:
Place of Origin: CHINA
Brand Name: YUECHEN
Certification: SGS BV
Model Number: AZ31B-H24
Payment & Shipping Terms:
Minimum Order Quantity: 1KG
Price: Negotiation
Packaging Details: plywood case
Supply Ability: 50Tonne per month
Detailed Product Description
Light Weight: Absorbs Vibration For Longer Life, While Retaining Dimensional Stability. Stablity: No Stress Relief After Machining; No Warps And Is Dent Resistant.
COSTS: Machine Dry, Without Oil Or Chemicals. TOOLING: 4 To 5 Times Greater Tool Life.
FINISH: Up To 5 Times More Machinable Than Rolled Aluminum. NONMAGNETIC: Good For Electrical And Computer Applications.
WEIGHT: Easier Handling Saves Energy And Time. FLATNESS: Eliminates Surface Machining.
WELDING: Strong Weldments Up To 95% Of Parent Metal, With Minimal Porosity. CORROSION RESISTANT: A Wide Variety Of Chemical Treatments Exists For Corrosion Protection, Alteration Of Surface Appearance, And To Provide A Base For Painting. Basic Engineering Precautions Averts Galvanic Corrosion.
STRENGTH: Excellent Strength And Stiffness Per Unit Weight. REPID HEAT: Ideal For A Broad Range Of Operating Temperatures, From 350 Degrees Fahrenheit To -30 Degrees Fahrenheit.
High Light:

AZ91D Magnesium Alloy Plate

,

AZ31B H26 Magnesium Alloy Plate

,

Rolled az91d magnesium alloy

Rolled AZ31B-H26 Magnesium Alloy Plate AZ91D magnesium plate Excellent Stiffness Energy Saving


Wrought magnesium tooling plate (Alloy AZ31B) has the following benefits and characteristics:

DAMPING Absorbs vibration for longer life, while retaining dimensional stability.
TOOLING 4 to 5 times greater tool life.
FINISH Up to 5 times more machinable than rolled aluminum.
COSTS Machine dry, without oil or chemicals.
WEIGHT Easier handling saves energy and time.
FLATNESS Eliminates surface machining.
STABILITY No stress relief after machining; no warps and is dent resistant.
WELDING Strong weldments up to 95% of parent metal, with minimal porosity.
ALKALI-RESISTANT Makes for easy cleaning.
CORROSION RESISTANT A wide variety of chemical treatments exists for corrosion protection, alteration of surface appearance, and to provide a base for painting. Basic engineering precautions averts galvanic corrosion.
STRENGTH Excellent strength and stiffness per unit weight.
NON-GALLING Sound and rugged surface, offering a low coefficient of friction and minimum wear,
REPID HEAT
DISSIPATION
Ideal for a broad range of operating temperatures, from 350 degrees Fahrenheit to -30 degrees Fahrenheit.
NONMAGNETIC Good for electrical and computer applications.
UNIT VOLUME
YIELD
Greater amount of finished magnesium material obtained, pound for pound.
SALVAGE Scrap retains a consistently high level of value.

Xi'an Yuechen Metal Products. Co., Ltd. (XYMCO) - a manufacturer specialized in the magnesium tooling plate, Magnesium alloy plate, magnesium alloy slab, magnesium alloy sheet, magnesium alloy bar, magnesium alloy tube, magnesium alloy billet, magnesium alloy rod, magnesium alloy rod, magnesium alloy pipe, magnesium welding wire, magnesium alloy profile, magnesium alloy forging, magnesium alloy casting, magnesium alloy machining part.
We comply with the specifications: AMS 4377G, AMS 4382, ASTM B90/B90M and ASTM B107.
Material grades: AZ31B, AZ61A, AZ80A, ZK60, AM50, AM60, AZ91, EQ21, EZ33, EV31, WE43, WE54 and ZE41.

Our main products and capacities are as follows:
1. Magnesium tooling plate: Max. Thickness: 300mm; Max. Width: 3000mm; Max. Length: 6000mm
2. Magnesium alloy slab: Max. Size: 400 x 1000 x 2500mm
3. Magnesium alloy sheet: Min. Thickness: 0.5mm; Max. Width: 600mm; Max. Length: 2000mm
4. Magnesium cast bar: Min. Diameter 90mm; Max. Diameter: 600mm; Max. Length: 6000mm
5. Magnesium extrusions:
Round tube: Max. OD 600mmx thickness 125mm Square tube: 430 x 430mm Flat bar: 920 x 160mm
U-Shape: 800 x 300mm Rectangular: 700 x 200mm
6. Magnesium alloy machined part according to customer
s design
7. Magnesium anode as per customer’s design

Our products already were exported to USA, Japan, Israel, India, Germany, Iran, Columbia, Italy and UK. Good quality, good price and good delivery.

Looking forward to your enquiry and hope a prosperous cooperation can be established between us.
Hot rolled AZ31B Magnesium alloy plate has good carving processing performance.
Because of its outstanding characteristics of magnesium plate engraving of low density, high specific stiffness, good damping property, environment friendly and no pollution, Recyclable good performance, known as the twenty-first Century green metal structure material. The magnesium plate engraving and mechanical processing of parts, in national defense, aerospace, electronic communication, rail transportation, medical equipment, printing plate, magnesium board carving mold and other fields, and has wide application prospect.

Our Advantage

Engraving process of magnesium board, cutting force, cutting energy consumption is low, less heat in the carving process, chip breaking, tool wear, prolong life, therefore, magnesium board for high-speed, high cutting the amount of cutting and engraving, which offset the magnesium plate engraving of higher price weakness in a certain extent.



Magnesium plate adopts the carving process of high speed cutting, has the following characteristics:

The feed speed engraving cutter can be improved more than 6 times; material removal rate can be increased by 5-6 times;
Magnesium aluminum plate surface roughness is greatly increased, up to 10 μ m;
Generally, carving cutting resistance magnesium plate to reduce the 1/3;
Magnesium plate engraving after hot deformation is low, can limit the work hardening;
Engraving tool durability increased nearly one times;
Magnesium plate engraving processing time can be significantly reduced, directly led to reduced processing cost;
Cutting resistance magnesium plate of small, good thermal conductivity, heat quickly, so the cutting speed is very fast, very few sticky knife. Engraving and cutting tool life is long, and shortens the required tool replacement in the carving process downtime
Advantage
Full range of product types, Ensure production capacity:
We ave advanced die-casting, extrusion, forging, rolling, casting processing production line and precision testing equipment. Can produce a variety of types of magnesium alloy and magnesium alloy products, and developed a high-strength magnesium alloy extruded sheet. Through the purification of ordinary magnesium, magnesium can be raised up to 99.99% of high purity.
Cost advantage:
Magnesium alloy casting production can customized as your requirement. the technical process is great, extrusion production required for a variety of bar, no need to purchase from abroad, extrusion molding products is easy molding, low energy consumption, saving production costs.



Rolled AZ31B H26 AZ91D Magnesium Alloy Plate 0
Rolled AZ31B H26 AZ91D Magnesium Alloy Plate 1


Our Services:
1. Small order quantity available
2. Professional engineering team and sales team
3. Payment: T/T & Western Union
4. OEM/ODM Supporttable
5. Free samples provided
6. Competitive price and high quality

FAQ:
1. Q: Are you a factory or trading company?
A: We are direct manufacturer located in Xi'an, Shaanxi province, and have our equipment!
2. Q: Are your products customized?
A: Yes,the products in the website are only the common type or the previous types, we can supply the new products according to your requirements or drawings.
3. I do not know how to use your product ?
Do not worry ! We can supply technical guidance together with products.
4. Q: How can I get some samples?
A: Several samples are freely offered for buidling the business long-term relationships and letting our customers believing the quality of our products.
