Product Details:
Payment & Shipping Terms:
|
Light Weight: | Density Is One-third The Weight Of Aluminium, One-fourth Of Steel | Machining Capability: | Easily Machined With Minimal Distortion And Is Capable Of Maintaining Tolerances That Are Within The Thousandths Range. |
---|---|---|---|
Material Alloys:: | AZ31B, AZ61A, AZ80A, AZ91D, AZ41M, ZK60, AM50, AM60, ZM21, MIA, ME20M, EQ21, WE43, WE54, ZE41 | Applications:: | Aerospace, Aviation, Textile Machinery, 3C, Mould/tooling, Vibration Testing System, Electronics, Automotive, Photoengraving And Power Generation Industries |
Higher Salvage Value: | Higher Salvage Value Than Aluminium And Steel When The Tool Is No Longer Needed | ||
High Light: | strongest magnesium alloy,light weight alloys |
Xi'an Yuechen Metal Products. Co., Ltd. (XYMCO) - a manufacturer specialized in the magnesium tooling plate, Magnesium alloy plate, magnesium alloy slab, magnesium alloy sheet, magnesium alloy bar, magnesium alloy tube, magnesium alloy billet, magnesium alloy rod, magnesium alloy rod, magnesium alloy pipe, magnesium welding wire, magnesium alloy profile, magnesium alloy forging, magnesium alloy casting, magnesium alloy machining part.
We comply with the specifications: AMS 4377G, AMS 4382, ASTM B90/B90M and ASTM B107.
Material grades: AZ31B, AZ61A, AZ80A, ZK60, AM50, AM60, AZ91, EQ21, EZ33, EV31, WE43, WE54 and ZE41.
Our main products and capacities are as follows:
1. Magnesium tooling plate: Max. Thickness: 300mm; Max. Width: 3000mm; Max. Length: 6000mm
2. Magnesium alloy slab: Max. Size: 400 x 1000 x 2500mm
3. Magnesium alloy sheet: Min. Thickness: 0.5mm; Max. Width: 600mm; Max. Length: 2000mm
4. Magnesium cast bar: Min. Diameter 90mm; Max. Diameter: 600mm; Max. Length: 6000mm
5. Magnesium extrusions:
Round tube: Max. OD 600mmx thickness 125mm Square tube: 430 x 430mm Flat bar: 920 x 160mm
U-Shape: 800 x 300mm Rectangular: 700 x 200mm
6. Magnesium alloy machined part according to customer’s design
7. Magnesium anode as per customer’s design
XYMCO stocks a wide range of magnesium alloy materials in various thickness, diameter and material grades - magnesium alloy plate, magnesium tooling plate, AZ31B-TP tooling plate, magnesium alloy sheet, Magnesium CNC engraving plate, Magnesium CNC engraving sheet, Magnesium tooling sheet, Magnesium extrusions, Cast magnesium tooling plate, magnesium alloy rod, magnesium alloy billet, magnesium alloy bar, magnesium welding rod, magnesium welding wire, magnesium flat bar, magnesium alloy ingot, Mg-RE (magnesium rare earth) alloy ingot, etc.
Using our “cut-to-size” and “cut-to-length” service, you can have immediate access to customized size magnesium materials at your finger tips. Simply input your dimensions, material grades and quantities and E-mail us to sales.magalloys@qq.com for a quick and easy metal-buying experience. Our principle is “one time business, long term friendship”.
Magnesium alloys have traditionally been specified by designers because of their favorable strength to weight ratios. Magnesium is approximately two thirds the density of aluminium and a quarter that of steel. Some of the more recently developed magnesium alloys have also improved resistance to corrosion and better all round mechanical properties, especially at elevated temperature.
The growing numbers of available magnesium alloys are divided into two groups: casting alloys and wrought alloys. Wrought product forms (described below) include both extruded sections and rolled sheet/plate along with tubes and forgings. Various heat treatments are used to attain maximum strength and machining of most magnesium alloys is excellent.
The specifications and alloy grades which XIAN YUECHEN METAL PRODUCTS CO., LTD. (XYMCO) can be complied with are as following Table:
DESCRIPTION |
ASTM Alloy Designation & Temper |
ASTM | FEDERAL | AMS | ||
AZ31B | Sheet - soft | AZ31B-O | B90 | QQ-M-44B | 4375 | |
Sheet - half hard | AZ31B-H24 | B90 | QQ-M-44B | 4377 | ||
Plate - soft | AZ31B-O | B90 | QQ-M-44B | 4375 | ||
Plate - half hard | AZ31B-H24 | B90 | QQ-M-44B | 4377 | ||
Plate- three quarters hard | AZ31B-H26 | B90 | QQ-M-44B | 4376 | ||
Plate - Extra flat | AZ31B-O | -- | 4382 | |||
Extruded bars & sections | AZ31B-F | B107 | QQ-M-31B | - | ||
AZ61A | Extruded bas & sections & forging stock | AZ61A-F | B107 | QQ-M-31B | 4350 | |
Extruded tube | AZ61A-F | B107 | WW-T-825B | - | ||
Forgings | AZ61A-F | B91 | QQ-M-40B | - | ||
AZ80A |
Extruded bars & sections |
precipitation treated | AZ80A-T5 | B107 | QQ-M-31B | - |
As-extruded | AZ80A-F | B91 | QQ-M-31B | - | ||
Forgings | precipitation treated | AZ80A-T5 | B91 | QQ-M-40B | 4360 | |
As-extruded | AZ80A-F | B91 | QQ-M-40B | |||
ZK60A |
Extruded bars & sections |
precipitation treated | ZK60A-T5 | B107 | QQ-M-31B | 4352 |
As-extruded | ZK60A-F | B107 | QQ-M-31B | - | ||
Forgings | precipitation treated | ZK60A-T5 | B91 | QQ-M-40B | 4362 | |
As-extruded | ZK60A-F | B91 | QQ-M-40B | - | ||
Magnesium Alloy Castings | AM50, AM60, A281, AZ91, EQ21, EZ33, EV31, WE43, WE54, ZE41 |
